1708FB

Front queen bed floorplan with no slideout, galley with dinette, and rear corner bathroom.

Build Yours
1708FB

Interior Decor Options

*Interiors are representations only and are subject to change.

Crosshatch

Crosshatch

Specifications

Weights & Measurements
Weights & Measurements
Exterior Length
19'5"
Exterior Height 1
10'5"
Exterior Width
7'0"
Awning Length
10'
Interior Height
6'4"
Freshwater Tank Capacity (gal.) 4
31
Water Heater Capacity (gal.)
6
Holding Tank Capacity — Black (gal.) 4
25
Holding Tank Capacity — Gray (gal.) 4
25
Holding Tank Capacity — Gray 1
25
Holding Tank Capacity — Gray 2
N/A
LP Capacity (lbs.) 5
40
GVWR (lbs.)
5,000
Sleeps 8
3
Axles (lbs.)
2 @ 3,000
Dry Weight (lbs.)
3,360
Furnace (BTU)
18,000
Dry Hitch Weight (lbs.)
340
Hitch Height
28"
Tire Size
235/75R15C
Interior
Interior

JBL Aura Cube- high performance mechless media center with parametric lighting
JBL Premium Sound interior speakers
LED TV
USB charge ports
Integrated Wi-Fi prep plate for router
Wireless cellphone charger
All-in-one control panel

Optional Equipment:
EZ Glide Sofa Sleeper with hutch and table (Only applicable on 1808FBS, 2100BH, 2108DS, 2108FBS, 2108TB, and 2306BHS) (Required on 2225RL)

Galley
Galley

Full-overlay European style cabinetry
Continuous waterfall style countertops and backsplash
Recessed single basin stainless steel sink (Not applicable on 1700BH)
Residential style pulldown faucet with sprayer
Recessed 3-burner cooktop with backlit knobs and glass cover (Not applicable on 1700BH)
Recessed 2-burner cooktop with glass cover (Only applicable on 1700BH)
Standard 10.3 cubic ft. 12-Volt refrigerator
1.1 cubic ft. convection microwave
Dream dinette table

Optional Equipment:
8 cubic ft. gas/electric refrigerator (Not applicable on 1700BH)

Bath
Bath

Dry bath on all floorplans

Bedroom
Bedroom

Versatile sleep arrangements

Exterior
Exterior

NXG engineered frame
2" frame mounted accessory receiver
1.5" FilonMax Fiberglass sidewalls with Azdel composite backing
Fully enclosed underbelly and tanks
One-piece thermo-foil insulation Gel-coat fiberglass front cap
Fully walkable roof decking with roof ladder
Dexter Torsion Axles with independent rubber suspension
15" Goodyear Wrangler Radial off-road tires
Aluminum wheel assemblies
Tire pressure monitor system prep
All LED exterior lighting with reverse lights integrated into the brake lights
Rearview backup camera prep
Patented powder coated exterior exoskeleton rack
Powder coated side gear storage box
Wi-Fi prep integrated into King Omni Antenna
Rear and off-camp side manual batwing awning with integrated outdoor shower privacy and exterior quick connect spray port
Portable induction cooktop for exterior kitchen
190-Watt solar panel with side-mount solar prep
Powered patio awning with integrated LED lighting
2 cubic ft. Truma portable cooler (Only applicable on 1316FB and 1316DB)
Lower Nerf bars integrated into frame
Protective front and side metal panels
Exterior patio side LP quick connect
Thick core pass-through storage doors with slam latch
Power tongue jack
Power stabilization jack
7-way plug holder
Triple solid entry step (Only applicable on 1708FB, and 1808FBS)

Standard dual 20lb. LP tanks

Heating & Cooling System
Heating & Cooling System

13,500 BTU A/C unit
Heated and enclosed holding tanks
Radiant foil insulation
12-Volt holding tank pad heaters with interior switch

Optional Equipment:
15,000 BTU A/C Unit

Electrical System
Electrical System
TV antenna
Roof-mount solar charge prep
(1) 190-watt solar panel with 30-amp charge control monitor and side-mount solar prep
Plumbing System
Plumbing System
6 gallon gas/electric/DSI water heater

Warranty
Warranty

3-Year Limited Structural Warranty & 1-Year Limited Base Warranty*

*See your dealer for complete warranty information.

Packages
Packages


Weights & Measurements

Exterior Length
19'5"
Exterior Height 1
10'5"
Exterior Width
7'0"
Awning Length
10'
Interior Height
6'4"
Freshwater Tank Capacity (gal.) 4
31
Water Heater Capacity (gal.)
6
Holding Tank Capacity — Black (gal.) 4
25
Holding Tank Capacity — Gray (gal.) 4
25
Holding Tank Capacity — Gray 1
25
Holding Tank Capacity — Gray 2
N/A
LP Capacity (lbs.) 5
40
GVWR (lbs.)
5,000
Sleeps 8
3
Axles (lbs.)
2 @ 3,000
Dry Weight (lbs.)
3,360
Furnace (BTU)
18,000
Dry Hitch Weight (lbs.)
340
Hitch Height
28"
Tire Size
235/75R15C
Winnebago Voyage Travel Trailer, winner of RV News 2022 Travel Trailer of the Year
